S7000 Series Bi-directional Programmable DC Power Supply (Low Voltage Version)
DC power supply
10~100V
5~30kW
The S7000 Series is a high precision, regenerative DC power source. As a DC source, it supports dual quadrant energy flow, with high conversion efficiency and high power density. It also supports parallel operation of multiple devices.
    • Automatic switching of source-load function
    • Power output range: 0 ~ 15kW
    • Current output range: 0 ~ 600A
    • Voltage output range: 0 ~ 100V
    • Parallel connection: up to 10 units
    • AC voltage input: 342VAC ~ 528VAC
    • PV simulation: Static MPPT, Multi-IV, EN50530, etc.
    • Automotive power curve: ISO16750-2, LV123, DIN40839,
    • Battery simulation: 6 fixed types, custom type
    • Battery charging and discharging test function
    • List mode, support multi-step programming
    • Custom waveforms: triangle, square, and sine.
    • RS232/LAN/USB communication interface
    • Protections: OVP, OCP, OTP, OPP, etc.
    • Remote voltage compensation
