FCTS-Mシリーズ燃料電池エンジン試験台
PEM
Fuel Cell Test
up to 400kW
FCTS-Mシリーズは、燃料電池システム向けに正確で安定性・信頼性に優れた試験台を提供することを目指しています。本試験台は主に、水素供給ユニット、熱管理ユニット、低電圧供給ユニット、安全保護ユニットで構成されています。燃料電池システムの機能、性能、耐用年数、信頼性、安全性の試験、ならびに燃料電池システムの研究開発、検証、最終試験(EOL)に適用可能です。
    • Double safety protection: hardware & software, with customizable alarm values.
    • Nitrogen purging, cooling circulation purging, the circulating water preheating, coolant replishment and gas exhaust, etc.
    • Electronic loads with wide range of voltages and currents, multiple operating modes: CV, CC, CP, etc.
    • Data recording and analysis capacities, automatic report generation and one-click export.
    • Test work-step predefined functions.
    • Dual operation mode: Manual/Auto, supports long periods unattended work.
    • Manual debugging function.
    • Online hydrogen leak alarm and online insulation detection.
    • Engine DBC file import & parsing.
    • The saved data can be viewed by CANOE software.
    • Hydrogen safety discharge channel: timely discharge in case of high hydrogen pressure due to failure of the pressure reducing valve.
    • Redundant design of safety.
